Typical Applications

  • Municipal water distribution – The pump can be used to supplying water in urban and rural areas through municipal water supply systems.

  • High-rise buildings – Suitable for providing  pressurized water across to tall structures ,ensuring consistent supply a cross different floors multiple floors.

  • Agricultural irrigation – The pump can be employed in farming and agriculture to deliver water to crops, ensuring proper hydration for optimal growth.

  • Industrial processes – Suitable for transferring liquids in various industrial applications ,such as manufacturing processes or chemical plants.

  • Commercial facilities – Used in settings like hotels ,resorts, and commercial buildings to transfer liquids for different purposes

Operating Conditions

  • Inlet: SAR 25–100 mm

  • Outlet: SAR 25–100 mm

  • Flow Capacity: 0.6–110 m³/h

  • Head Pressure: 6–300 m

  • Power Range: 0.37–45 kW

Technical Data

Model Motor P2 (kW) Motor P2 (HP) Supply / Voltage Range Full Load In (A) Start DOL Ist (A) Soft Start Iss (A) Motor Eff. (%) Rated Flow Q (m³/h) Head at Rated Q (m) Max. Head (m) Max. Flow (m³/h) Speed (rpm) Max. Pressure (bar) DN B1 (mm) B2 (mm) B1+B2 (mm) D1 (mm) D2 (mm) Weight (kg)
SAR 2-2 0.37 0.5 1~ 220-240 V 2.7 12 8.2 62 2 15 18 3.5 2900 1.8 DN25 258 225 483 148 117 20
SAR 2-3 0.37 0.5 1~ 220-240 V 2.7 12 8.2 62 2 22 27 3.5 2900 2.6 DN25 276 225 501 148 117 20
SAR 2-4 0.55 0.75 1~ 220-240 V 3.9 17 12 65 2 30 36 3.5 2900 3.5 DN25 294 225 519 148 117 22
SAR 2-5 0.55 0.75 1~ 220-240 V 3.9 17 12 65 2 37 45 3.5 2900 4.4 DN25 312 225 537 148 117 23
SAR 2-6 0.75 1 1~ 220-240 V 5 23 15 68 2 45 53 3.5 2900 5.2 DN25 340 245 585 170 142 26
SAR 2-7 0.75 1 1~ 220-240 V 5 23 15 68 2 52 63 3.5 2900 6.2 DN25 358 245 603 170 142 26
SAR 2-9 1.1 1.5 1~ 220-240 V 7.2 32 22 70 2 67 80 3.5 2900 7.8 DN25 394 245 639 170 142 28
SAR 2-11 1.1 1.5 1~ 220-240 V 7.2 32 22 70 2 82 98 3.5 2900 9.6 DN25 430 245 675 170 142 29
SAR 2-13 1.5 2 1~ 220-240 V 9.5 43 29 72 2 98 116 3.5 2900 11.4 DN25 476 290 766 190 155 35
SAR 2-15 1.5 2 1~ 220-240 V 9.5 43 29 72 2 112 134 3.5 2900 13.1 DN25 512 290 802 190 155 36
SAR 2-18 2.2 3 1~ 220-240 V 14 61 41 74 2 136 161 3.5 2900 15.8 DN25 566 290 856 190 155 41
SAR 2-22 2.2 3 1~ 220-240 V 14 61 41 74 2 165 197 3.5 2900 19.3 DN25 638 290 928 190 155 42
SAR 2-26 3 4 3~ 380-415 V 5.9 38 18 85.8 2 198 232 3.5 2900 22.7 DN25 720 345 1065 197 165 52



Product Videos

Datasheet/Downloads SAR 2 Datasheet
