Typical Applications

Water supply: raw-water transfer, ﬁltration and boosting duties in waterworks, district distribution, high-rise pressure boosting and packaged booster sets.
Industrial pressure boosting: process water systems, washing and cleaning plant and high-pressure ﬂushing systems.
Industrial liquid transfer: cooling and air-conditioning circuits, boiler feed and condensate systems, machine-tool coolant supply, and mild acids and alkalis.
Water treatment: ultra-ﬁltration, reverse osmosis, distillation, separators and swimming-pool circulation.
Irrigation: ﬁeld and farm irrigation, sprinkler systems and drip irrigation.

Operating Conditions

Thin, clean, non-ﬂammable and non-explosive liquids, free of solid particles or ﬁbres.
Liquid temperature: standard version −15 °C to +70 °C; hot-water version +70 °C to +120 °C.
Maximum ambient temperature +40 °C; maximum installation altitude 1000 m.
Maximum pressure generated ranges from 2.5 bar on SAR 200-1-B to 15.4 bar on SAR 200-4, model by model — see Technical Data.
Suction and discharge ﬂanges to PN25-40/DN150.
Suction and discharge ports are in line and of equal bore, allowing the pump to be installed directly in a straight pipe run.
Pump head and motor are coupled by a rigid spacer coupling, so the mechanical seal can be changed without disturbing the pipework.
Non-self-priming: the pump must be fully primed and the required NPSH maintained at the inlet to avoid cavitation.
Above +40 °C ambient or above 1000 m altitude the motor output is derated and a larger motor frame must be selected.
Motor totally enclosed, fan-cooled, protection IP55, insulation class F.
Optional intelligent controller protects against dry running, phase failure and overload.

Technical Data

Model	Motor P2		Supply / voltage range	Current at 50 Hz (A)			Motor eff. (%)	Rated flow Q (m³/h)	Head at rated Q (m)	Max. head (m)	Max. flow (m³/h)	Speed (rpm)	Max. press. (bar)	DN	Dimensions (mm)					Weight (kg)
Model	kW	HP	Supply / voltage range	Full load In	Start DOL Ist	Soft start Iss	Motor eff. (%)	Rated flow Q (m³/h)	Head at rated Q (m)	Max. head (m)	Max. flow (m³/h)	Speed (rpm)	Max. press. (bar)	DN	B1	B2	B1+B2	D1	D2	Weight (kg)
SAR 200-1-B	18.5	25	3~ 380-415 V	33	233	100	91	200	20	25.5	240	2950	2.5	DN150	907	550	1457	330	255	311
SAR 200-1-A	22	30	3~ 380-415 V	40	277	119	91.3	200	24	29	240	2950	2.8	DN150	907	575	1482	360	285	347
SAR 200-1	30	40	3~ 380-415 V	53	374	160	92	200	34	38.5	240	2950	3.8	DN150	907	650	1557	400	310	403
SAR 200-2-2B	37	50	3~ 380-415 V	66	460	197	92.4	200	41	53	240	2950	5.2	DN150	1101	650	1751	400	310	447
SAR 200-2-2A	45	60	3~ 380-415 V	80	557	239	92.8	200	49	59.5	240	2950	5.8	DN150	1101	685	1786	460	340	504
SAR 200-2-A	55	75	3~ 380-415 V	96	671	287	93.1	200	59	69	240	2950	6.8	DN150	1131	760	1891	540	370	595
SAR 200-2	55	75	3~ 380-415 V	96	671	287	93.1	200	69	78.5	240	2950	7.7	DN150	1131	760	1891	540	370	595
SAR 200-3-2B	75	100	3~ 380-415 V	130	909	389	93.7	200	75	91.5	240	2950	9	DN150	1325	845	2170	580	410	748
SAR 200-3-A-B	75	100	3~ 380-415 V	130	909	389	93.7	200	79	95	240	2950	9.3	DN150	1325	845	2170	580	410	748
SAR 200-3-2A	75	100	3~ 380-415 V	130	909	389	93.7	200	84	99.5	240	2950	9.8	DN150	1325	845	2170	580	410	748
SAR 200-3-B	75	100	3~ 380-415 V	130	909	389	93.7	200	89	104.5	240	2950	10.2	DN150	1325	845	2170	580	410	748
SAR 200-3-A	75	100	3~ 380-415 V	130	909	389	93.7	200	93	108	240	2950	10.6	DN150	1325	845	2170	580	410	748
SAR 200-3	90	125	3~ 380-415 V	155	1087	466	94	200	103	117.5	240	2950	11.5	DN150	1325	895	2220	580	410	817
SAR 200-4-2B	90	125	3~ 380-415 V	155	1087	466	94	200	110	131.5	240	2950	12.9	DN150	1519	895	2414	580	410	830
SAR 200-4-2A	110	150	3~ 380-415 V	189	1324	568	94.3	200	118	138.5	240	2950	13.6	DN150	1519	1140	2659	645	550	1180
SAR 200-4-A	110	150	3~ 380-415 V	189	1324	568	94.3	200	128	148	240	2950	14.5	DN150	1519	1140	2659	645	550	1180
SAR 200-4	110	150	3~ 380-415 V	189	1324	568	94.3	200	138	157.5	240	2950	15.4	DN150	1519	1140	2659	645	550	1180

Product Videos

Datasheet/Downloads SAR 200 Datasheet
