SSP 30

SSP 30
SSP 30ssp_30


The add to cart button will appear once you select the values above

Typical Applications

  • Boreholes and Wells: Deep extraction of non-aggressive liquids up to 300m depth.
  • Water Supply Systems: Reliable high pressure water extraction for domestic, commercial and agricultural use.
  •  Irrigation Systems: Efficient water transportation for irrigation purposes in fields and gardens.
  •  Industrial Applications: Corrosion resistant pump for water transfer in various industrial processes.
     Ground water Management: Effective extraction of water from significant depths for control and prevention.
  •  Mining and Construction: Dewatering solution for removing water from underground mines and excavations.

Operating Conditions

  •  Pumped Liquid: Thin, clean chemically non-aggressive liquids without solid particles or fibres.
  •  Max. Liquid Temperature: +40°C
  •  Max. Water Depth: 300m
  •  Min. Borehole Diameter: 200m
  •  Enclosure Class : IP68
  •  Insulation Class: F
  •  Voltage: 3x415V
  •  Speed:2900rpm

Motor

  • Rewindable motor
  • Insulation Class B
  • Protection IP68
  • Speed RPM 2850

Technical Data

Model
Supply
 Motor P2 Current at 50 Hz (A)
Stages
Max. head (m)
Max. flow (m³/h)
Outlet
 Dimensions (mm)
Weight (kg)
kW HP Operating In Starting Ist Ø D P M T
SSP 30-6 220-240 V / 380-415 V 5.5 7.5 25 / 11 112 / 50 6 69 42 2½", 3" — — 614 — —
SSP 30-8 380-415 V 7.5 10 16.5 74 8 92 42 2½", 3" — — 654 — —
SSP 30-14 380-415 V 13 17.5 28.6 129 14 160 42 2½", 3" — — 804 — —
SSP 30-16 380-415 V 15 20 33 148 16 183 42 2½", 3" — — 854 — —
SSP 30-20 380-415 V 18.5 25 40.7 183 20 229 42 2½", 3" — — 934 — —
SSP 30-22 380-415 V 22 30 48.4 218 22 252 42 2½", 3" — — 1014 — —
SSP 30-27 380-415 V 26 35 57.2 257 27 309 42 2½", 3" — — 1094 — —
SSP 30-29 380-415 V 26 35 57.2 257 29 332 42 2½", 3" — — 1094 — —
SSP 30-34 380-415 V 30 40 65 292 34 389 42 2½", 3" — — 1174 — —



Product Videos

Datasheet/Downloads SSP 30 Datasheet
