ENGINE SERVICE KITS
A range of cost-effective service kits comprising Oil Filters, Fuel Filters and Air Cleaners packaged conveniently to suit scheduled service of the different engine models within the Dayliff range. Engine kit component details are available on request.
DF DC Fuel Transfer Pump
A self-priming rotary vane DC type pump specifically designed for diesel or kerosene transfer. They are particularly suited for use on generators for the transfer of fuel from bulk storage to main supply tanks. The pump features a cast iron body and composite vane impeller and is fitted with either a 12 or 24V DC brush motor with PMG stator, to suit the battery voltage of the system.
| Parameter |
Specifications |
| Max Flow (L/min) |
70 |
| Max Head (m) |
15 |
| Suction (m) |
3 |
| Working Voltage |
DC 12V or 24V |
| Power (kW) |
0.55 |
| Speed (rpm) |
2800 |
| Inlet / Outlet (") |
1x1 |
| Dimensions (mm) |
200x160x120 |
| Weight (kg) |
3 |
Manual Changeover Switch
A range of Manual switches changing input power from mains supply to generator. They feature 4-pole switches and are fitted with indicator lights to show connection status.
| Genset Range |
Model No. |
Changeover Rating |
| 20kVA, 3Phase |
MCO-32 |
32A |
| 25kVA, 3Phase |
MCO-40 |
40A |
| 40kVA, 3Phase |
MCO-63 |
63A |
| 65kVA, 3Phase |
MCO-100 |
100A |
Automatic Transfer Switches (ATS)
The Dayliff range of Auto Transfer Switches are specially designed for automatic switching of power supply between mains and generator inputs according to load requirements. They are specificied for applications with Dayliff generators fitted with DSE modules and include motorised 4-pole breakers powered by a signal from the module. Manual power change over is also provided. The units are fitted with indicator lights to show active power and connection status.
| Generator Range |
Model No. |
Breaker Rating |
| 9-80kVA |
ATS125 |
125A |
| 85-100kVA |
ATS160 |
160A |
| 110-160kVA |
ATS250 |
250A |
| 165-250kVA |
ATS400 |
400A |
| 260-400kVA |
ATS630 |
630A |
