Satte SGP C



Typical Applications

  • Residential Power Backup: Reliable and quiet generators for uninterrupted home power supply during outages.
  •  Commercial/Industrial Backup: Robust units for stable power in factories, data centers, and commercial buildings.
  • Construction/Remote Sites: Portable generators with extended fuel capacity for reliable power in remote locations.
  • Telecommunications/Broadcasting: Dependable power for communication infrastructure in remote or outage-prone areas.
  • Healthcare Facilities: Continuous power support for hospitals, clinics, and medical centers with real-time monitoring.
  • Emergency Services: Essential power backup for fire stations, police stations, and disaster response centers.
  • Off-Grid Power: Reliable off-grid electricity for remote cabins, research facilities, and off-grid homes.
  • Please note that the specified ratings are applicable at sea level. For higher altitudes, derate the sets by 1% per 100m and by 2% per 5°C above 20°C.

Technical Data

GENERATOR MODEL SGC 45C SGC 64C SGC 80C SGC 104C SGC 144C SGC 200C SGC 250C SGC 280C
Prime/Standby
Power Output
KVA 56/63 80/88 100/110 130/143 180/200 250/275 313/350 350/375
KW 45/50 64/70 80/88 104/114 144/158 200/220 250/280 280/300
Engine Data
Type Cummins
4BTA3.9-G2
Cummins
4BTA3.9-G11
Cummins
6BT5.9-G2
Cummins
6BTAA5.9-G2
Cummins
6CTA8.3-G2
Cummins
NT855-GA
Cummins
NTA855-G1B
Cummins
NTA855-G2A
Rated Power @ 1500rpm (kW) 55 70 86 120 180 231 284 310
Max Power @ 1500rpm (kW) 50 80 92 130 163 254 321 313
Aspiration Turbo charged & Aftercooled
No. of cylinders 4 6
Displacement (L) 3.9 5.9 8.3 14
Fuel Consumption (litres/hr)
10 13.2 17 23 30 41.3 54.3 54.9
12.9 17.6 22 30 40 53.4 71.4 71.9
Fuel Tank Size (litres) 130 280 330 770
Dimensions &
Weights
Length, A (mm) 2300 2800 42000
Width, B (mm) 1100 15000
Height, C (mm) 1290 1470 1800 2100
Dry Weight (kgs) 1320 1410 1600 1700 4050 4250 4300
Downloads SGC Datasheet
