Typical Applications
- Agricultural Irrigation: Efficiently powers water pumps for crop irrigation in remote farming areas.
- Compatible with submersible pumps, surface pumps, swimming pool pumps using induction motors.
- Aquaculture: Drives pumps to ensure adequate water circulation in fish farms.
- Remote Villages: Supplies water for domestic use in rural communities without grid access.
- Desert Greening Projects: Supports irrigation systems for reforestation and desert farming.
- Hilly or Mountainous Regions: Facilitates water lifting in challenging terrains where power infrastructure is absent.
- Municipal Water Supply: Enhances water supply systems in towns with unreliable power.
- Solar-Powered Fountains: Operates water fountains in public parks or private gardens sustainably
Rated Conversion Efficiency : ≥98%
MPPT Efficiency : 99%
Ambient Temperature : -20~60℃
Display : LED
Protection Grade :IP52 (Protection Grade)
| Rated Power |
11 kW |
| Max. DC Input Current |
13 A |
| Max. DC Input Voltage |
430 V |
| Recommended MPP Voltage |
90 - 360 V |
| AC Input Voltage |
1PH 85 - 265 V |
| Max. AC Input Current |
13 A |
| Adapting Motor Power |
0.37 - 0.75 kW |
| Adapting Motor Voltage |
1PH 220 - 240 V |
| Rated AC Output Current |
6.3 A |
| Output Frequency |
0 - 50/60 Hz |
| MPPT Efficiency |
99% |
| Rated Conversion Efficiency |
98% |
| Ambient Temperature |
-20 - +60°C |
| Cooling Method |
forced air cooling |
| Display |
LED |
| Protection Grade |
P65 |
Technical Data
| Model |
Rated voltage |
Insert max DC=Input volt(V)
|
Recommended MPP Voltage(V)
|
Rate Power |
Rated AC Output Current (A) |
Dimensions (mm) |
Weight (Kg) |
| 1x 240V |
3x 415V |
kW |
L |
W |
H |
| SLVL4 2.2 |
1x 240V
|
|
440 |
180-360 |
2.2 |
11 |
266 |
296 |
111 |
7 |
| SLV3 2.2 |
|
450 |
280-370 |
3.7 |
17 |
257 |
416 |
158 |
9.2 |
| SLV3 3.7 |
3x 415V
|
450 |
310-370 |
3.7 |
17 |
257 |
416 |
158 |
9.2 |
| SLV3 5.5 |
|
850 |
500-700 |
5.5 |
13 |
257 |
416 |
158 |
9.2 |
| SLV3 7.5 |
|
850 |
500-701 |
7.5 |
18 |
257 |
416 |
158 |
9.2 |
| SLV3 11 |
|
850 |
500-700 |
11 |
24 |
300 |
458 |
175 |
13 |
| SLV3 15 |
|
850 |
500-700 |
15 |
30 |
300 |
458 |
175 |
13 |
| SLV3 18 |
|
850 |
500-701 |
19 |
39 |
300 |
458 |
175 |
13 |
| SLV3 22 |
|
850 |
500-702 |
22 |
45 |
300 |
458 |
175 |
13 |
| SLV3 30 |
|
780 |
500-600 |
30 |
60 |
388 |
625 |
235 |
40 |
| SLV3 37 |
|
780 |
500-601 |
37 |
75 |
388 |
625 |
235 |
40 |
| SLV3 45 |
|
780 |
500-602 |
45 |
92 |
388 |
625 |
235 |
40 |
