5SSP 20

5SSP 20

Typical Applications

Clean water pumping
Well pumping
River pumping
Farm irrigation
Water supply systems
Mining operations
Drainage in breeding industry

Operating Conditions

Water temperature up to 35°C
Ambient temperature permissible up to 40°C
5SSP Minimum internal diameter of well: 5"(130mm)
Maximum sand content: 0.25%
Maximum immersion depth: 80m

Motor

Rewindable motor
Insulation Class B
Protection Ip68
Speed RPM -2850

Technical Data

MODEL	POWER		Max Current(A)	Voltage V	Dimensions (mm)			Weight(kg)			Recomended Controllers (kW)
MODEL	KW	HP	Max Current(A)	Voltage V	C	B	A	C	B	A	Recomended Controllers (kW)
5SSP 20-10	7.5	10	18.9		712	655	1367	12.57	37.7	50.27	11
5SSP 20-12	11	15	24.2	380	808	740	1548	14.37	45.3	59.67	15
5SSP 20-18	15	20	32		1128	905	2001	19.77	59.6	79.37	18

Downloads 5SSP 20 Datasheet
